Lauda PD 2 G User Manual

09/2020 Puridest Glass Distillation Apparatus 17 / 34
PD 8 G
Exterior dimensions (W x D x H)
685 mm x 360 mm x 410 mm
Distillation capacity
8 l / h mono distillate
Distillate quality
Mono distillate
approx. 2.2 µS / cm at 25 °C
in conformity with DAB, bacteria and pyrogen free,
low gas content.
The conductivity of the distilled water is directly related to the chemical composition of the raw water. Components of the raw water having the same
or a lower evaporation point than water may deteriorate the conductivity.
Cooling water required
144 l / h
Low water cut-off
Electromechanical temperature limiter, with capillary
tube sensor.
Switch-off temperature 135 °C / -15 K
Water pressure min. / max.
> 3 bar / 7 bar
> 43.5 psi / 101.5 psi
Electrical connection
Mains supply
Internal fuse
On-site fuse
220 V / 3 ~ / PE, +/-10 %, 50 / 60 Hz, 6.0 kW
Mains connection cable for permanent connection to
the mains, on-site 3 x 25 A inert
or
400 V / 3 ~ / N / PE, +/-10 %, 50 / 60 Hz, 6.0 kW
Mains connection cable for permanent connection to
the mains, on-site 3 x 16 A inert
Caution! Mains voltage deviations, even with the mentioned limits, influence the quantity of distillate produced.
Protection class / - type
I / IP20
Surrounding conditions
Use only inside buildings (not in potentially explosive
areas).
Height above MSL
up to 2000 m MSL
Ambient temperature
+10 °C to +40 °C
Humidity
max. 80 % rel. humidity to 31 °C, decreasing to 40 %
rel. humidity at 40 °C
Net Weight
26.0 kg
Weight with water filling
34.0 kg
