Lauda PD 2 R - PD 8 R Mains Connection Examples; PD 8 R Mains Connection (230 V;1~ to 220 V;3~); PD 8 R Mains Connection (230 V;1~ to 400 V;3~)

0
9
/2020
Puridest
Distillation Apparatus
21
/
30
13.1.3 PD 8 R for 230 V / 1 ~ for a mains supply of 220 V / 3 ~ / PE / 50 / 60 Hz
(see nameplate)
PD 8 R
Mains connection through on-site switch S4, all-pole sepa-
rable from the mains. Connection cable not in scope of
supply.
13.1.4 PD 8 R for 230 V / 1 ~ for a mains supply of 400 V / 3 ~ / N / PE / 50 / 60 Hz
(see nameplate)
PD 8 R
Mains connection through CEE plug in conformity with IEC
standard 60309-2, all-pole separable from the mains. Con-
nection cable and CEE plug not in scope of supply.
