13 Connection to the mains supply
Distillation Apparatus models PD 2 and PD 4 are supplied with a pre-assembled, cast-on shock-proof plug (CEE 7/7).
Make sure to connect to a protective conductor terminal.
Colour coding of the mains cable
Mains supply
ge/gr
–
yellow
/
green
PE (
Protective earth
)
bl
–
bl
u
e
N
sw
–
black
L1
Models PD 2 and PD 4 supplied for 230 V (see information on the nameplate) can be connected to all power supplies of
220 V or 230 V.
Electrical fuses 13.1
Model
Power
Power consumption at mains voltage
*
Mains
fuse (F4, F5)
PD 2
2
.
0 kW
8.
7 A
at
230
V
10 A
mp
PD 4
3
.
0
kW
13.
0 A
at
230
V
16 A
mp
* seenameplate
