3.3 SETUP OF THE ULTRACOOL UNIT (UC 80 AND UC 100)
Front of the UC 100
1. External controller display
2. Status and Warning/Alarm LEDs
3. Front panel. It gives access to the electrical box
4. Main power switch
5. Condenser (cool air intake)
6. Power and communications cables inlet (below the unit)
