Technical Features
7 Technical Features
UC 140 Indigo 50Hz 140 Indigo 60Hz
Cooling capacity kW (ton) 15.3 (4.3) 17.4 (4.9)
Water flow l/h (US gal/min) 2628 (11.6) 2566 (11.3)
Water pressure bar (psi) 5.1 (74) 4.8 (70)
Refrigerant charge kg (lb) R134a 14 (31) 14 (31)
Compressor kW 4.0 5.3
Condenser kW (ton) 24.0 (6.8) 24.0 (6.8)
Evaporator kW (ton) 19.4 (5.5) 19.4 (5.5)
kW 0.7 1.0
Motor fan
m3/h (scfm) 8300 (4885) 8300 (4885)
kW 1.1 1.0
max flow 4000 (17.6) 4000 (17.6)
min flow
l/h (US gal/min)
400 (1.8) 400 (1.8)
max pres. 6.3 (91) 6.3 (91)
Water pump
min pres.
bar (psi)
3.3 (48) 3.3 (48)
Water tank volume litre (US gal) 100 (26) 100 (26)
Water connections 1" BSP 1" NPT
Front mm (in) 845 (33) 845 (33)
Depth mm (in) 990 (39) 990 (39)
Dimensions
Height mm (in) 1235 (49) 1235 (49)
Weight kg (lb) 260 (573) 260 (573)
Power kW 5.8 7.3
Max. Current A 16 30
Voltage V/P/Hz 400/3/50 Hz 230/3/60 Hz
Nominal COP 3.26 2.76
All data related to the following conditions: Water outlet temperature 10ºC (50ºF) and ambient
temperature 25ºC (77ºF).
UC-140 INDIGO 50/60Hz 29.01.03 rev. 0
