Launch CRT5011E

LAUNCH
19
2
MEMORY CARD
SLOT
Insert the memory card into it to read or
write the data/le stored in the memory
card.
3
BUTTON Press it to trigger the vehicle sensor.
4
BUTTON
Quick access to Help function.
5
BUTTON Returns to previous menu.
6
BUTTON
• When in MENU mode, scroll UP
through the menu and submenu line
by line.
• When in DATA VIEW mode, scroll
through the screen data to the
PREVIOUS page.
BUTTON
When in MENU/DATA VIEW mode, scroll
through the screen to the PREVIOUS
page.
BUTTON
• When in MENU mode, scroll DOWN
through the menu and submenu line
by line.
• When in DATA VIEW mode, scroll
through the screen data to the NEXT
page.
BUTTON
When in MENU/DATA VIEW mode, scroll
through the screen to the PREVIOUS
page.
7 OK BUTTON
Conrms a selection (or action) from a
MENU list.
8
DB-15 DIAGNOSTIC
CONNECTOR
Connects the tool to the vehicle’s Data
Link Connector (DLC).
