LAUNCH 440(440W) 455(455W) Installation Manual
20
No Material code Name
1 201020712 FL column
2 201020698 Locking latch plate assembly
3
103030114
Hexagon nut C class M20 GB41-86
4
103040138
Washer C class 20 GB95-85
5
103030143 Thin nut A,B class M20 GB6172-86
6
103100080
Quick L type air fitting APL8-02（for FRL
UNIT）
103100215
Quick T type fitting APE6（440W、455W）
7 102160383 FRL UNIT WAW2000-02
8 103201926
Manual solenoid valve（auto reset）
TSV98322S
103100214
Quick L type air fitting APL6-02（solenoid
valve）
9 103201504 Bracket of air valve
10 104090094 Quick hose fitting AD34.5 ZD-SM
11
103020133 Screw M10*25 GB/T5780-86
12
103040122 Flat washer 10 GB/T93-87
13
103040123 Spring washer 10 GB/T95-85
14
201011363 Bracket of power unit
15
103020134 Screw M6*15 GB/T5789-86
16
103990154
Power unit （220/380V 50/60HZ）
17 103201512 Turn around fitting
18
201020708
Right column
19
201020711 Rear column
20
103250169 Name plate
21
103010481 Rivet 3*6 GB/T867-86
