Combine identification
Combine type and serial number appear on the
plate and are also punched into the rear right-hand
side of the frame (1).
Fig. 4
GUID-A9142C5E-E332-42C2-ADE8-CCF4956F6D9C-high.jpg [High]
1.3.2 Engine Identification
The engine is identified by the type plate (1) in the
middle of the cylinder block.
The following information appears on the plate (1):
•
Manufacturer
• type
• Engine power and rated speed
• Engine serial number
• Valve clearance
• Customer reference code
• Idling speed
• Compliance with Directive 97/68/EC
• Name of the engine assembler.
The engine serial number is always also stamped
on the cylinder block.
Fig. 5
GUID-BE36C15A-6DDF-4936-94EB-581D2BEFA0DE-high.jpg [High]
GUID-7554F332-5E42-406F-8EA8-5AC1BE9EAC4C [V1]
1. General Information
22 Combines
M300-M310_EN_327305015
