Lawn Devil DB8605 - Installing the Grass Bag; Installing the Side Discharge Chute

7
Installing the Grass Bag
1. Raise and hold up the Rear Deflector (Figure 5).
(Figure 5)
2. Install the Grass Bag, ensuring that the 2 grass bag pins rest in the Notches on
the handle (Figure 5).
3. Lower the Rear Deflector.
Installing the Side Discharge Chute
Lift up the Side Deflector and install the Side Discharge Chute (Figure 6).
(Figure 6)
A: Notch x 2
B: Grass bag pin x 2
C: Rear Deflector
