Technical Data
Model Number
DB8605
Engine Type
4 stroke
Engine Displacement
196cc
Discharging
Yes
Mulching
Yes
Bagging
Yes
Height Adjustment
8 positions,1- 3-1/4 inches
Cutting Width
22" (560mm)
Front Wheel
8 inch
Rear Wheel
10 inch
Fuel Tank Capacity
0.24 Gal / 0.9L
Oil Tank Capacity
18 ounces / 0.55L
Grass Bag Capacity
15 Gal / 55L
OPERATION GUIDANCE
Filling the Engine with Oil
This engine is shipped from factory without oil. Check oil level before starting
engine (Figure 7), if you start the engine without oil, the engine will be damaged
beyond repair and will not be covered under warranty.
Your mower does not come with oil in the engine. Max. fill: 18 ounces
SAE 10W-30 is recommended for general use.
Please refer to Engine Manual for more details.
(Figure 7)
Filling the Fuel Tank
Gasoline
is extremely flammable and explosive. A fire or explosion from gasoline
can burn you and others.
To prevent a static charge from igniting the gasoline, place the container
and/or mower directly on the ground before filling, not in a vehicle or on an
object.
