ASSEMBLY
the boundary wire and the boundary (Fig. 6).
Ŷ,IWKHODZQLVERUGHUHGE\DOHYHOVXUIDFHHJDSDWKRUGULYHZD\WKDWLVOHYHOZLWKWKHODZQWKH
boundary wire can be laid along the edge of the path or driveway, so that the mower can cut
right over the edges. Make sure the width of the path or driveway must be more than 1m (Fig. 7).
Ŷ,WLVSRVVLEOHWROHWWKHERXQGDU\ZLUHFURVVWKHZRUNLQJDUHDLIWKHUHLVDVPDOOGLS8VHDSHJWR
secure the boundary wire into the ground, and make sure the wire is as close as possible to the
ground. This ensures the blades of the mower never come in contact with the boundary wire (Fig.
8).
NOTE: Extra boundary wire should be cut off to avoid disrupting the robotic lawnmower. Extra wire
must not be placed in coils outside the boundary wire (Fig. 9).
Smooth turns
Maintain at least 90° angle at all left-turn corners when laying the boundary wire along the boundary.
Secure the boundary wire with pegs at every turning point.
'RQRWOD\WKHERXQGDU\ZLUHDWVKDUSDQJOHVRULWZLOOEHGLI¿FXOWIRUWKHURERWLFODZQPRZHUWRIROORZ
the boundary wire (Fig. 10).
Slopes
The robotic mower has the ability to safely climb slopes of 35%, and areas that are steeper than this
should be isolated with the boundary wire (Fig. 11).
7RFDOFXODWHWKHVORSHRI\RXUODZQVHH)LJ7KHVORSHZRXOGEH
Perimeter islands
,IWKHUHDUHÀRZHUEHGVSRQGVRUVPDOOWUHHVLQWKHODZQFUHDWHSHULPHWHULVODQGVWRSURWHFWWKHP
Lay the boundary wire clockwise around the obstacle to make sure the mower can work properly
around it. Between the two parallel boundary wires, it should be less than 1cm wide (Fig. 12).
Where the distance between two islands is more than 1m, the boundary wire is suggested to be laid
out as illustrated (Fig. 14).
The boundary wire must not be crossed on its way to and from an island (Fig. 13).
WARNING
The mower must not run over gravel or similar material which can damage the blades.
WARNING
35cm (Elevation)
100cm (Length)
35% (slope)
