KNOW YOUR BLOWER
The safe use of this product requires an understanding of the information on the product and in this
Operator’s Manual, as well as knowledge of the project you are attempting. Before use of this product,
familiarize yourself with all operating features and safety rules.
Components
1. Shoulder Straps 18. Fuel Tank
2. Battery Release Button 19. Fuel Tank Cap
3. Charging Port 20. Primer Bulb
4. Battery Pack 21. Engine Housing
5. Battery Indicator 22. Spark Plug Cap
6. Start Button 23. Backpack Harness
7. Throttle Lever 24. Choke Lever
8. Blower Nozzle 25. Air Filter Knob
9. Front Blower Tube 26. Air Filter Cover
10. Rear Blower Tube 27. Waist Strap
11. Handle 28. Cruise Control Lever
12. Flexible Hose 29. Stop Switch
13. Hose Clamp 30. Start Button Cover
14. Elbow Tube 31. Chest Strap
15. Black Frame 32. Charger
16. Mufer with Spark Arrestor 33. Charging Connector
17. Rear Engine Housing
