35
NOPULL
TM
STARTER SYSTEM
%5HGÀDVKLQJRIWKHEDWWHU\LQGLFDWRU/('LQGLFDWHVWKDWEDWWHU\YROWDJHLVWRRORZDQGQHHGVWREH
charged.
&*UHHQÀDVKLQJRIWKHEDWWHU\LQGLFDWRU/('LQGLFDWHVWKDWDVKRUWFLUFXLWRFFXUVLQWKHHOHFWULFVWDUWHU
Check the electric motor and the motor drive lines as below:
Open the corrugated pipe buckle and disconnect the male and female terminals of the motor drive
OLQHVEOXH)LJ3UHVVWKHVWDUWEXWWRQDQGFKHFNLIWKH/('ÀDVKHVJUHHQ/('GRHVQRWÀDVK
WKHVKRUWFLUFXLWRFFXUVLQWKHHOHFWULFPRWRURUWKHPRWRUGULYHOLQHVRIWKHHQJLQH/('ÀDVKHVJUHHQ
the short circuit occurs in the motor drive lines of the handle.
'$OWHUQDWHUHGDQGJUHHQÀDVKLQJRIWKHEDWWHU\LQGLFDWRU/('LQGLFDWHVWKDWDQRYHUFXUUHQWRFFXUVLQ
the electric starter part. Check if the engine is stuck and cannot be rotated smoothly. Check if there
LVDQ\IRUHLJQPDWWHUVXFKDVPHWDOPDJQHWL]HGRQWKHÀ\ZKHHO
E. If the battery indicator LED is continuously on, check that if an open circuit occurs from the PCB
output to the motor connecting line.
When pressing the start button and the LED is continuously on, test the voltage output in the motor
drive lines using the DC voltage stall of multimeter (Fig. 70).
If there is voltage output, the possible causes are as below:
1). The electric motor has broken down;
2). The motor drive lines of the engine have detached from their welding position to the electric
motor;
3). There is loose or failed contact in the connection from the motor drive lines of the engine to the
male and female terminals in the corrugated pipe buckle.
If there is no voltage output, the possible causes are as below:
1). The motor drive lines of the handle have detached from their welding position to the PCB;
2). There is loose or failed contact in the connection from the motor drive lines of the handle to the
male and female terminals in the corrugated pipe buckle.
Fig. 69
5HG
Black (-)
Terminals of
motor drive
lines (Blue)
Fig. 70
Test by
multimeter
To Next Page
