T
utorial
mc²66 V1.3/0 41/ 68
5. Now press the PAGE button, located above the trackball,
to access the second page of soft key functions.
The displays above the four soft keys update to show EDIT and
S
TEP functions.
6. Press the STEP button to activate the step forward mode.
7. Now deselect PAGE and press the CONN soft key to
make the first route.
The Signals display updates with a green line showing the route
between M
ic_06.1 and Inp 1. In addition, the source and
destination selections automatically step down to the next
entries in the list.
8. Continue pressing the CONN button until all eight
microphone sources are connected to input channels 1 to
8.
As you step down through the list, note the red and white
crosses which appear to indicate routes are made to or from
sources and destinations within the list.
9. Now repeat the reverse bus assign operation, as described
on Page 37, to assign all eight input channels onto Sum 1
for monitoring.
