LAZBOY Limited - Routine Maintenance and Winterizing

Page 42
For HELP, call In-Touch at 866.461.3123
Error Codes
CODE DESCRIPTION
CORRECTIVE ACTION
COM Topside error
•
Swap topside plug position (C1 to C2)
•
Change topside control panel
bL Er
CP Er
O3 Er
P1 Er
P2 Er
P3 Er
Device not
detected
or
air-locked
pump
•
Open the access panel to spa pack and
reseat corresponding plug (see callouts on
page 43)
• Reset GFCI breaker
• Reset Br and LL settings (see page 43)
•
Bleed air from system (see page 39)
Rh Er Heater
malfunction
•
Reseat both red heater plugs
•
Change heater
Rh HL Water high
limit temp.
exceeded
•
Add cold water to spa (see Filling Your
Spa on page 18)
• Turn on Pump 1 to circulate water
• Shade spa from intense direct sun with
Gazebo or other structure
Rh nC Heater not
connected
properly
•
Open the access panel to spa pack and
reseat small red “Rh” plug
• Remove red “Rh” plug and check for bent
pins – remove red collar
•
Reset GFCI breaker
Rh nf Water not
flowing
properly
•
Check for closed jets and closed slide
valves on heater and pumps
• Check for dirty filter/plugged return line
• Check for proper water level (see Filling
Your Spa on page 18)
• Close air control valves
•
See also Circulation Pump on page 40
Rh nH No heat
•
Open the access panel to spa pack and
reseat both red heater plugs
• Reset GFCI breaker
•
Reset Br and LL settings (see page 43)
SP br Improper BR
setting
Administer BR current to proper setting (see
Low-Level Settings on page 43)
SP F1 F1 blown Change F1 (Buss Fuse Class G #SC-20)
SP F2 F2 blown Change F2 (Buss Fuse Class G #SC-30)
SP F3 F3 blown Change F3 (Buss Fuse Class G #SC-30)
SP Hr Internal
hardware error
•
Reset circuit breakers on GFCI panel and
main circuit breaker panel
•
Turn on/off all pumps and accessories
