Lea LE25326D - Detailed Description of the Product; Technical Characteristics

1
DETAILED DESCRIPTION OF THE PRODUCT
1. Transmission.
2. Throttle trigger.
3. Switch ON/OFF.
4. Safety lever.
5. Ratchet.
6. Starter handle.
7. Choke.
8. Primer.
9. Handlebar.
10. Air filter cover.
11. Fuel cap.
12. Fuel tank.
13. Guard support.
14. Protector.
15. Nylon head.
16. Nylon cutting blade.
17. Blade.
18. Gear Box.
19. Hitch of harness.
TECHNICAL CHARACTERISTICS
Model LE25326D
LE25427D
LE25517D
Displacement (cm
3
) 36,2 42,7 51,7
Maximum power (kW)
1,05 1,25 1,45
Engine/Fuel ratio 2Stroke /Gasoline 40 : Oil 1
Maximum engine speed(min
-1
) 9000
Maximum rotaion of the head tool(min
-1
)
6700
Idle speed (min
-1
) 3000
Fuel tank capacity . L 0,9 1,2 1,2
Unit mass (empty tanks without cutting
attachment)
6,8 7,5 7,5
Vibration level (ISO 22867) (m/s
2
) 7,5
Sound pressure level (dB(A)) 96
Guaranteed sound power level (dB(A)) 114
