Lead LD-BK10 Series - Sensing Cable Assembly

Note：correspondence between leader color of sensor and phase:
Yellow corresponds to phase A; Green corresponds to phase B;
Red corresponds to phase C; Blue corresponds to channel d.
(1) D25 sensing cable (3-wire system), Cable length tolerances: ±2.5%
Connection diagram of type D/E/F 3-channel sensing assembly
06
2. Sensing Cable Assembly
传感电缆插头
LA
LB
LC
Red
Green
Yellow
Connection diagram of type G/I 4-channel sensing assembly
传感电缆插头
LA
LB
LC，Ld
Red
Blue
Green
Yellow
Pt100 sensor
Cable
D25 sensor assembly plug
Pt100 sensor
Cable
D25 sensor assembly plug
