Lead LD-BK10 Series - Technical Specifications; Operating Conditions; Measurement Accuracy; Contact Capacity

03

The technical specif ication
1. Operating conditions
-30.0℃～240.0℃
2. Range of measurement
Grade of accuracy: Grade 1(Grade 0.5 for temperature controller, Grade B for
sensor);
Resolution: 0.1℃
3. Measurement accuracy
400mm×320mm×120mm(H×W×D)
4. Overall dimension
≤12W
5. Power consumption of temperature controller
About 5kg
6. Weight
Capacity of contact of fan: 16A/250VAC (cosΦ=0.4);
Capacity of control output: 5A/250VAC (Resistance); 5A/30VDC
7. Contact capacity
JB/T7631-2016 Electronic Thermo-controllers for Transformers
ISO9001:2015 Quality Management Systems-requirements
Ambient temperature: -20℃～+55℃;
Relative humidity: < 95％(25℃);
Power frequency: 50Hz or 60Hz(±2Hz);
Power voltage: AC220V(+10%, -15%);
or AC380V (+10%, -15%);
(If there is no special indication when ordering, AC220V shall
prevail)
8. Standards of design and production
