Lead LD-BK10 Series - Page 6

CJX2-1810
NXB-63
C25
400V-
50Hz
6000A
02
LD-BK10
The sensor cable must be removed from the controller before the withstand voltage test to prevent
damage to the controller.
在进行耐压测试前，必须将传感电缆从温控器上卸下，以防损坏温控器。
Max
Ci
rc
M
anu Alarm
Trip
Fault
Fan Run
Manu/Auto
Max/Circ
最大
风机运行
Fan Fault
风机故障
手动/自动 最大/巡回
巡回
超温
跳闸
故障
手动
Layout of controller：
Indicators
Indicators
Operation key
The lock
Sensor assembly
outlet hole
Sensor assembly
socket
Terminal block
Micro Circuit
Breaker
outlet hole
LED display
