6. Temperature Simulation (P1012):
Simulate the change of temperature value and detect the output of controller.
14
Fan star
Over-temp
alarm
Out of range
Fan stop
Over-temp alarm
release
In range
Normal display status
① To prevent the transformer from wrong tripping, the software doesn’t support
analogue function of over-temperature tripping;
② The actual operating temperature point shall be subject to the internal parameter
of temperature controller (1005 function setting).
Note:
