To select the desired line
voltage, proceed
as follows:
(1) DISCONNECTTHE INSTRU-
MENT FROM THE POWER
SOURCE,
(2) Remove screw on the right
side
of the instrument then
take the cover
off. (Ref:
Fig.
3-1)
(3)
Move the Line Voltage Se-
lector to the desired voltage
position. (Ref: Fig. 3-3)
LINE VOLTAGE SELECTOR
Fig. 3-2
Block diagram
AF
IN/OUT
IC 102
OUT ONLY
SIG SELECT
I C 101
XTAL.
