17.12 Turning User Payload ID On and Off
To turn user payload ID on and off, follow the procedure below.
When the user pattern is selected, turning it ON outputs the user payload ID information.
You can edit the user payload ID only in a web browser.
How to edit, see 22.2.11 “Editing User Payload ID.”
Procedure
12G OPTION → SDI 1 → VIDEO → USER PAYLAD → ON/OFF
Parameters
ON / OFF
17.13 Configuring Embedded Audio
16 (HD(DL)) audio channels (32 channels for 3G-B) can be embedded in an SDI signal.
For the setting procedure, see 12.10, “Configuring Embedded Audio.”
17.14 Common SDI Signal Settings
You can link the SDI2 and SDI3 settings to the SDI1 setting and the SDI4 setting to the SDI3
setting by following the procedure below to select ON.
When linked, SDI2 to SDI4 cannot be set.
Procedure
12G OPTION → SDI 2 → EQUAL TO SDI 1
12G OPTION → SDI 3 → EQUAL TO SDI 1
12G OPTION → SDI 4 → EQUAL TO SDI 3
Parameters
ON / OFF
４．ＳＤＩ ＵＳＥＲ ＰＡＹＬＯＡＤ
□ＯＮ ■ＯＦＦ
２．１２Ｇ ＥＱＵＡＬ ＴＯ ＳＤＩ １
■ＯＮ □ＯＦＦ
２．１２Ｇ ＥＱＵＡＬ ＴＯ ＳＤＩ ３
■ＯＮ □ＯＦＦ
