Digital Stepper Drive Hardware Installation Manual
1. Family Overview
Introduction
The DM stepper drive is fully digital stepper drive developed with advanced DSP control algorithm based on the latest motion control
technology. It has achieved a unique level of system smoothness, providing optimal torque and nulls mid-range instability. Its motor
auto-identification and parameter auto-configuration feature offers quick setup to optimal modes with different motors. Compared with
traditional analog drives, DM stepper drive can power a stepper motor at much lower noise, lower heating, and smoother movement. Its
unique features make DM drive an ideal choice for high requirement applications.
Product Covered
The DM series stepper drives can be divided into two groups as follows:
 Low voltage DM drives includes DM320C, DM422C, DM422, DM432C, DM442, DM556 and DM856
 High voltage DM drives includes DM1182 and DM2282
This manual describes how to install and configure the above stepper drives.
Low Voltage DM Stepper Drives
Part Number
Input Voltage
(VDC)
Typical Supply Voltage
(VDC)
Output Current
(Amp)
Pulse Frequency
(KHz)
DM320C 18-30 24 0.5-2.0 70
DM422C 18-40 24 0.3-2.2 75
DM422 18-40 24 0.3-2.2 75
DM432C 18-40 24 0.3-3.2 200
DM442 18-40 24 0.5-4.2 200
DM556 18-50 36 0.5-5.6 200
DM856 18-80 68 0.5-5.6 200
DM870 18-80 68 0.5-7.0 200
High Voltage DM Stepper Drives
Part Number
Input Voltage
(VAC)
Typical Supply Voltage
(VAC)
Output Current
(Amp)
Pulse Frequency
(KHz)
DM1182 80-150 110 0.5-8.2 200
DM2282 80-220 220 0.5-8.2 200
