Polystyrene Alloy Taping Specifications
10 sprocket hole pitch cumulative tolerance ±0.20mm
Carrier camber is within 1mm in 250mm
A0 and B0 measured on a plane 0.3mm above the bottom of the pocket
K0 measured from a plane on the inside bottom of the pocket to the top surface of the carrier
Material: black anti-static polystyrene alloy
All dimensions meet EIA-481-3 requirements
Thickness: 0.50±0.05cm
Packing length per 22” reel: 50.0 Meters (1:2)
Component load per 15” reel: 1000 pcs. (SUR-56-3-XL)
Polystyrene Alloy Taping Drawing
