LR9548S GPS Module Technical Manual v1.52
© 2006 Leadtek Research Inc. All rights reserved. Page 4/20
Preliminar
y
Confidential - Information is sub
j
ect
t
o chan
g
e without
p
rior notice.
Environmental Characteristics
Items Description
Operating temperature range -40 deg. C to +85 deg. C
Storage temperature range -55 deg. C to +100 deg. C
Physical Characteristics
Items Description
Length
24 mm ± 0.1mm (0.94in)
Width
20 mm ± 0.1mm (0.79 in)
Height
2.9 mm ± 0.1mm (0.11 in)
Weight 2.5g
Interface Specifications
Items Description
I/O 28 pin SMD micro package
