LEADZM LZ-910 - Installation Steps

Install front wheel one:
Use L (M8 spanner) to loose ②(M8 nuts) from ③(front axle)
(counterclockwise rotation), and take down ①(M8 shim).
①
②
③③
①
②
③③
L
Installation Steps
Front direction
Install rear wheel one:
①
②
③③
③③
①
②
L
Install front wheel two:
Install G(wheel) onto the ③(front axle) as shown in the figure, then place ①
(M8 shim) on ③(front axle). Use L(M8 spanner) to fix ②(M8 nut) on ③(front
axle) (clockwise rotation).then install H(small wheel cover) onto the right
place on G(wheel).
①
②
③③
H
G G
③③
①
②
H
L
7
8
Use L (M8 spanner) to loose ②(M8 nuts) from ③(rear axle)
(counterclockwise rotation), and take down ①(M8 shim).
Front direction
Front direction
G
③③
①
②
H
①
②
③③
H
G
L
Install rear wheel two:
Install G(wheel) onto the ③(rear axle) as shown in the figure, then place
①(M8 shim) on ③(rear axle). Use L(M8 spanner) to fix②(M8 nut) on
③(rear axle) (clockwise rotation).Then install H(small wheel cover) onto
the right place on G(wheel).
Front direction
