LHDMI44: MAIN MATRIX UNIT
FEATURE
SPECIFICATION
1
INPUTS: DIGITAL-AUDIO/VIDEO
(4x) HDMI inputs
VIDEO FORMATS:
480p,576p,720p50/60,1080i50/60,1080p50/60,HDMI1.
4 Mandatory 3D formats as a minimum.DVI formats.
AUDIO FORMATS:
LPCM,AC3,DTS,DD+,DTS-HD (in Multichannel mode)
2
OUTPUTS: HDBaseT
(4x) HDBase-T Outputs Uncompressed HD video -
Supports all formats as in item 1.
One cable carries: Video, Audio, IR, RS232.
3
SYSTEM CONTROL
(1x) RJ12 Leaf Proprietary Remote control
(1x) RS232 DB9 IN
(1x) RS232 DB9 LOOPOUT
Bank select and termination selectors.
4
INFRA RED REMOTE CONTROL
THROUGHPUT ONLY
(No direct control by IR)
(4x) DIRECTIONAL IR INPUTs. Support for: Direct IR, IR
TX Bug, IR RX Bug. Modulated 38Khz and Envelope.
5
DISPLAY/KEYS
Front Panel with 2 push switches and 8 LEDs enable
basic selection and display of the connections within
the matrix.
6
PHYSICAL LAYOUT
RACK MOUNTABLE (1RU+)
REMOTE HDBaseT RJ45s, AND LEDS AT FRONT
ALL OTHER CONNECTORS AT REAR
RJ12 FOR CONNECTION TO TC3 CONTROLLER
USER INTERFACE (BASIC): 2 BUTTONS 8 LEDS.
STANDARD RACK EARS AND FEET INCLUDED.
7
RANGE (Cable Distance)
Expected achievable range between LHDMI44 and the
connected Zone LB1’s is up to approximately 60 metres
for Cat5 /6 cable and up to approximately 70 metres
for Cat6a cable.
7
NUMBER OF INPUTS/OUTPUT
4 /4
8
EXPANDABILITY
Bank Select Switch
9
POWER
40W 3.3A 12V DC. Consumption depends on resolution
of distributed video and features enabled.
60W supply included – Use Leaf Audio supply only.
10
DIMENSIONS (W, D, H)
Approx 425mm x 290mm, x 55mm
