LT2020E: MAIN MATRIX UNIT
FEATURE
SPECIFICATION
1
INPUTS: DIGITAL-AUDIO/VIDEO
(20x) HDMI inputs
VIDEO FORMATS:
480p,576p,720p50/60,1080i50/60,1080p50/60,HDMI1.
4 Mandatory 3D formats as a minimum.DVI formats.
AUDIO FORMATS:
LPCM,AC3,DTS,DD+,DTS-HD (in Multichannel mode)
2
ETHERNET PORTS.
(16x) ETHERNET INPUTS
100Base-Tx full-duplex Ethernet on all ports
3
OUTPUTS: HDBaseT
(16x) HDBase-T Outputs Uncompressed HD video -
Supports all formats as in item 1.
One cable carries: Video, Audio, Ethernet, IR, RS232.
4
OUTPUTS: LOCAL AUDIO
(16x) 2Ch RCA ANALOG OUTPUTS
FORMAT: Analog Stereo. Programmable audio delay
Sources for these audio outputs may be routed
independently from HDMI inputs, remote (breakout) or
local SPDIF inputs.
INPUTS: LOCAL AUDIO
(16X) S/PDIF INPUTS
5
SYSTEM CONTROL
(1x) RJ12 Leaf Proprietary Remote control
(1x) RS232 DB9 IN
(1x) RS232 DB9 LOOPOUT
Bank select and termination selectors.
6
INFRA RED REMOTE CONTROL
THROUGHPUT ONLY
(No direct control by IR)
(16x) DIRECTIONAL IR INPUTs. Support for: Direct IR,
IR TX Bug, IR RX Bug. Modulated 38Khz and Envelope.
(16x) RJ45 RS-232 PORT for remote control to
breakouts. Up to 115200 Baud.
7
DISPLAY/CONTROL
Front Panel Touch Screen, enables basic selection and
display of the connections within the matrix.
8
PHYSICAL LAYOUT
RACK MOUNTABLE (3RU)
REMOTE ETHERNET AND HDBaseT RJ45s, AND TOUCH
SCREEN AT FRONT
ALL OTHER CONNECTORS AT REAR
RJ12 FOR CONNECTION TO LEAF CONTROLLER
USER INTERFACE (BASIC): TOUCHSCREEN PANEL.
STANDARD RACK EARS AND FEET INCLUDED.
9
NUMBER OF INPUTS/OUTPUT
20 /16
10
EXPANDABILITY
Bank Select Switch and Audio Breakaway
11
POWER
60W 5A 12V DC. Consumption depends on resolution
of distributed video and features enabled.
120W supply included – Use Leaf Audio supply only.
12
DIMENSIONS (W, D, H)
418(484 incl rack ears) x 290mm, x 133mm(147mm incl
feet)
