p.8 MyWay User Manual
8.0 Main Frame Set-Up/Features
8.1 Frame | Unfolding the Frame
• Lift the frame out of the box and set it on a
at, stable surface, keeping it in the same
position as it was packaged within the box
i.e. as per image below.
• Stand at the base of the frame’s
‘U’ shape. Pull both triggers.
• Walk the frame’s front legs forward,
away from you (in direction of arrows),
engaging the front castors until the legs
are fully extended. Release both triggers.
Warning – when lifting the
frame, adhere to normal
moving and handling
procedures.
Warning – ngers should
be placed on triggers as
shown, to avoid potential
for nger nipping.
Warning – if the red rectangle is visible
on the triggers once these have been
released, the frame legs have not been
fully locked out.
