7.10 Attaching the
Sandals
Place the sandal so that the attachment bolt
goes through the slot in the footplate. To
secure, on the underside of the footplate
place the rubber washer (a), followed by
the metal washer (b) and then the knob (c)
onto the attachment bolt. To position the
sandals simply loosen the knob (c) under
the footplate, select the position you require
and re-fasten the knob.
2
1
C
A
B
C
3
D
C
