LECTRO 36VDC - Fig. 1-3, Pole Mount (Rear View of Cabinet)

To Next Page

To Previous Page

745-573-B0-001 REV. A

1.0 Overview, Continued

GROUND

POLE MOUNTING

BRACKET

AC INPUT

CONDUIT

CONNECTION

OPTIONAL

LOCATION FOR

"FEED-THRU" ADAPTOR

DISCONNECT BREAKER BOX

COAX SEIZURE CLAMP

"SNAP IN" CONNECTOR

(TO POWER SUPPLY INPUT)

"FEED THRU" ADAPTOR AT

REAR

OF BOTTOM SHELF

1.2 Cabinet Nomenclature, continued

Fig. 1-3, Pole Mount (Rear View of cabinet)

Fig. 1-4, Typical Placement of Disconnect Breaker on rear of Cabinet

Fig. 1-5, Coax “Feed Thru” Adapter Normal Location (Bottom Shelf)
