Lectronix T7000 - Audio Line in (Front); USB (Front); USB (Rear); AM;FM Antenna Connector (AM;FM;WB)

20
Vehicle Power, Audio & I/O (cont.)
Audio Line In (front)
Pin
Description
Tip
Left
Center
Right
Outer
GND
USB (front)
Pin Number
Description
1
USB3 +5V Power
2
USB3 -
3
USB3 +
4
USB3 GND
USB (rear)
Pin Number
Description
1
USB1 +5V Power
2
USB1 -
3
USB1 +
4
NC
5
USB1 GND
AM/FM Antenna Connector (AM/FM/WB)
Pin
Description
Center
Antenna
Outer Shell
GND
C6
CAN RT
120ohm resistor
C7
Undefined
No Connect
C8
Undefined
No Connect
C9
Undefined
No Connect
C10
Undefined
No Connect
C11
Undefined
No Connect
C12
Undefined
No Connect
C13
Aux Dash /Left
Audio line in left
C14
Aux Dash /Right
Audio line in right
C15
Aux Dash Common
Audio return
C16
Undefined
No Connect
C17
Undefined
No Connect
C18
Undefined
No Connect
C19
Undefined
No Connect
C20
Undefined
No Connect
F1
Battery Power Fuse Pin 1
Passive
F2
Battery Power Fuse Pin 2
Passive
