T7000 Connector Definitions (cont.)
TPMS Antenna Connector (TPMS)
Pin Number
Description
I/O
1
Center
Antenna
2-5
Outer Shell
GND
GPS Antenna (GPS)
Pin Number
Description
I/O
1
Center
Antenna
2-5
Outer Shell
GND
Internal Satellite Module ( int SDAR)
Pin Number
Description
I/O
1
Center
Antenna
2-5
Outer Shell
GND
External Satellite Module (ext. SDAR)
Pin Number
Description
I/O
1
SDAR Power (+12V)
Output
2
SDAR Enable
Output
3
SDAR Serial Transmit
Input
4
Digital Ground
5
SDAR Audio Right
Input
6
SDAR Serial Receive
Output
7
SDAR Audio Return
Input
8
SDAR Audio Left
Input
Outer Shell
Earth Ground
Video (VIDEO)
Pin
Number
Description
Pin
Number
Description
1
LIN+
13
Video_OUT+
2
LIN-
14
Video_OUT-
3
Earth Ground
15
Camera Input 4 -
4
No Connect
16
Camera Input 4 +
5
Earth Ground
17
Earth Ground
6
Camera 3 Ground
18
Camera Input 3 -
7
Camera 3 Power
19
Camera Input 3 +
8
Camera 2 Ground
20
Camera Input 2 -
9
Camera 2 Power
21
Camera Input 2 +
10
Earth Ground
22
Earth Ground
11
Camera 1 Ground
23
Camera Input 1 -
12
Camera 1 Power
24
Camera Input 1 +
