11
UHF Compact Receiver
Rio Rancho, NM – USA
SPECIFICATIONS AND FEATURES
Operating Frequencies: 470MHz to 608MHz, crystal controlled
Sensitivity: Better than 0.35 uV for 20dB SINAD;
1.5 uV for 50dB S/N ratio
Signal/Noise Ratio: 106dB A-weighted
Squelch Quieting: greater than 106dB
AM Rejection: -60dB (10uV to 0.1 Volts)
Modulation Acceptance: ±15kHz
Image and Spurious Rejection: greater than 100dB
Third Order Intercept: -5 dBm
Audio Outputs:
XLR: 200 Ohms balanced; 100mV max.
Headphone: 0.6 Volts RMS into 50 Ohms
Antenna Input: BNC; 50 Ohms impedance
Controls: Front panel attenuator controls XLR output.
Recessed trim-pot controls headphone 3 position
power/function switch.
Indicators: Red LED for power “ON” (Battery status)
2 LEDs for modulation level
“RF” LED for transmitter “ON”
Power Requirements: 11.5 to 18VDC external (either polarity)
110 VAC via CH-12 AC adapter
Single 9 Volt alkaline battery
Power consumption: 60mA at idle;
70mA at 15kHz deviation, with headphones
Battery Life: 5 hours with alkaline
Weight: 11 ounces including battery
Dimensions: 1.1" x 2.75" x 5.2"
Specifications subject to change without notice.
