SAFETY PRIMER FEED INSTRUCTIONS
1
INSTALL appropriate primer
arm. Cycle up and down to
insure proper orientation.
3
DEPRESS primer latch on
tray, rotate counterclock-
wise and li o cover.
5
SLIDE the trough and tray
together again, making
sure that they snap completely
together.
8
LOWER ram (raise
handle) to seat the
primers. The primers
should be lush to slight-
ly below lush when
properly seated.
6
SLIDE primer eed into
case eed bracket.
7
DE-PRIME and size case
as normal. With ram at the
top o the stroke (handle down),
push the trigger on the primer
eed to dispense a primer.
Trigger has to be ully
orward, then down to dispense
a primer.
4
PLACE no more than
primers in tray and
shake side to side to tip primers
upright,
CHANGING primer sizes
can be done in seconds!
• Replace L-shaped primer arm
with appropriate size
• Substitute appropriate
feed assembly
SELECT correct primer eed assembly
large white trigger assembly
small black trigger assembly
2
INSTALL primer eed bracket using supplied washer and
bolt as pictured. Orient bracket with eeder installed to
lever prime. Snug bolt with /” wrench.
#90997
SOLD SEPARATELY
* SMOOTH OPERATION TIP Spent primers are extremely dirty, and aer extended use it my be necessary
to clean ram where primer lever is inserted. Clean the ram using gun scrubber, electrical contact cleaner or
disc brake cleaner. Be sure to lubricate outside of ram with #30 weight motor oil or equivalent.
SMALL
BP2889A
LARGE
BP2889B
