4a. Recessed into the wall
4a.1. Build the framing by 2x6” stud, below picture of 50” as an example.
Dimensions for all sizes are listed below. The appliance will be
10
supported by the om framing, make sure the b om framing it
solid and level. Leave some gap behind the right stud for electrical
supply.
Model unit
EF385A EF286A EF287A EF288A EF289A
A
Inch
48 13/1638
986810 1240 1494 1800
13/1631 57/64 58 13/16
70 55/64
mm
4a.2. Prepare electrical supply.
4a.3. Fix the plasterboard to edge of the framed opening. Paint it or cover
it with wall paper to nish the wall. BUT ledger stone is NOT suitable.
11
2x6”stud
right stud
18 5/16”
6”
2”
