4b.3. Take away the bracket and drill 3pcs 40mm deep, holes on the
wall. Tap the plas c wall plugs into the holes. Secure the bracket by
3pcs ST5X40 screws.
If the wall is solid wood, it is no need to drill the holes on the wood
and use plas c wall plugs.
Wall
Floor
for concrete wall only
4b.4. Fit the slots in the back of rebox over the hooks on the bracket,
and carefully hang the rebox on the bracket. Then secure the
screws on both sides.
Wall
Floor
16
