TYPICAL USES
LEHLE P-SPLIT III AS A SPLITTER FOR TWO AMPS
The LEHLE P-SPLIT III operates as a split-
ter for one instrument to two amps. Use
the shortest cables possible to connect
instruments with passive pickups to the
input of the LEHLE P-SPLIT III.
Most musicians find the sound of two am-
plifiers working in parallel extremely pow-
erful and simply big.
HOW TO DO THIS
1. Connect your instrument to the input
socket of the LEHLE P-SPLIT III.
2. Connect the first amplifier to the DIR
socket (2).
3. Connect the ISO socket (5) to the input
of the second amp.
4. Use the phase inverter switch (3) to de-
termine which setting you prefer.
5. Use the ground lift switch (4) to find the
position at which noise is minimised.
6. There you go!
DEVICE CONNECTION
DIR
ISO
MADE IN GERMANY
P-SPLIT
Input
Output
Instrument
Amplifier 1
Output Amplifier 2
ISO
DIR
