LEHLE GmbH · Germany · www.lehle.com · support@lehle.com
LEHLE P-SPLIT III AS A RECORDING SPLITTER
It can be very useful, when recording gui-
tar or bass, to record not only the ampli-
fied signal, but also the dry (unprocessed)
signal. This signal can then be routed in
the mix either to a real amplifier, or to a
digital emulator, for editing.
It’s also helpful to be able to hear your
accustomed sound from an amp while
recording the dry signal.
In this configuration, the LEHLE P-SPLIT III
again functions as a neutral splitter.
HOW TO DO THIS
1. Connect your instrument to the input
(1) of the LEHLE P-SPLIT III.
2. Connect your amp to the DIR output
socket (2).
3. Connect the ISO socket (5) to the Hi-Z
input of a sound card or DAW.
4. Use the ground lift switch (4) to deter-
mine which position eliminates the most
background noise.
5. There you go!
DEVICE CONNECTION
Input
Output
Instrument (active)
Amplifier
Output Sound card (Hi-Z)
ISO
DIR
DIR
ISO
MADE IN GERMANY
P-SPLIT
