Technical data
Weight: 356 g (without Battery)
Length: 9 cm
Width: 9.2 cm
Overall height: 3.9 cm
Voltage range: 9 - 20 V AC or DC, or 9V PP3 battery
Max. power take-up: 9 mA
Frequency response: 20 Hz - 100 kHz (in mode D)
Distortion: 0.001 % at 1kHz, 0 dBU
Impedance, Input D: 1 MOhm
Impedance, Input S: 4 MOhm
Impedance, Output: 150 Ohm
Signal-to-noise ratio: -103 dB at 1 kHz , 0 dBU (A-weighted)
Max. level: 5.7 V RMS (approx. 17 dBU)
Max. gain: 15 dB
