Group 7 Data/Programming Page 101
Release R2.0 LEIBINGER JET3
Distance between two print-outs. This option is only
available for the job list type <Job organisator>. It
refers to print-outs created by the <PrintGo
Repeat> option. Please see example.
Number of repetitions with each PrintGo signal. This
option is only available for the job list type <Job
organisator>. Please see example.
The print-out will be carried out until a <PrintStop>
command occurs. This option is only available for
the job list type <Job organisator>. Please see
example at the end of this chapter.
Defines the source and the edge to be evaluated of
the PrintGo signal
<PrintStop interrupts print-
out immediately> (25)
With this option ticked off the current print-out will
not be finished but interrupted immediately in case a
<PrintStop> command occurs
With this option ticked off an additional print start
query will be activated using a separate PrintGo Gate
sensor. The print-out will only start as long as the
monitored sensor is active. Additionally it can be
defined which kind of signal level shall be recognized
as “active”.
The encoder source can either be external
(hardware encoder) or internal (defining the speed).
In this display field the resolution of the used
encoder has to be defined in pulses per millimeter.
There has to be an internal speed defined in case no
external encoder is used.
For an external encoder it can be defined which
rotational directions shall be detected.
<Speed dependent
output> (32)
The digital outputs of the JET3 printer can be linked
with the measured speed. The assigned output
switches to high level once the set speed is reached
/exceeded. The assigned output switches back to
low level when the speed falls 10% below the set
speed.
Please see chapter Speed dependent output for
details.
With this option ticked-off the backward
movements of an external encoder will be ignored.
