Leibinger Jet 3 - Page 105

Group 7 Table of contents Page 103
Release R2.0 JET3
Figure 39
Menu bar Job list creator
1 – Menu bar <Joblist Creator>
17 – Checkbox <mirrored>
1a – Drop-down menu <Joblist>
18 – Button <OK>
1b – Drop-down menu <Edit>
19 – Button <Cancel>
1c – Drop-down menu <Joblist sett.>
20 – Tab <PrintGo Parameter>
2 – Option <Save Joblist>
21 – Display field <PrintGo Distance>
3 – Option <Save Joblist as>
22 – Display field <PrintGo Repeat>
4 – Option <Load Joblist to print>
23 – Checkbox <endless>
5 – Option <Close Joblist Creator>
24 – Settings <PrintGo Source>
6 – Dialog box <Save file as>
25 – Checkbox <PrintStop immed.>
7 – Option <Import Job >
26 – Settings <PrintGo gate>
8 – Option <Delete Job>
27 – Tab <Encoder Parameter>
9 – Dialog box <Open file>
28 – Settings <Encoder Source>
10 – Option <Printstyle>
29 – Settings <Encoder Resolution>
11 – Option <Print Parameter>
30 – Settings <intern Speed>
12 – Option <Encoder Parameter>
31 – Settings <Encoder Direction>
13 – Option <Date change Param.>
32 – Settings <Speed dependent out.>
14 – Tab <Printstyle>
33 – Checkbox lock backward>
15 – Display field <Print height>
34 – Tab <Date Change Parameter>
16 – Display field <Orientation>
35 – Settings <Date Change Offset>
1
2
3
4
5
6
7
8
9
10
11
12
13
26
14
15
16
17
18
19
20
21
22
23
24
25
18,19
18
19
34
35
18
19
33
32
31
30
28
27
29
1a
1b
1c
