Group 7 Data/Programming Page 167
Release R2.0 LEIBINGER JET3
An additional function allows to select and export the current machine relevant data.
With the button <Export> (6) you can save the recorded machine relevant data on
an external memory device (e.g. USB-stick).
The button <Close> (10) closes the window.
7.4.5.1 Select (call up) log file
Press the button <ServiceFunctions> (1) and the option <Data Logging> (2) or
the accordant direct button (Icon) (3).
The window <Data Logging> (4) is faded in.
The recorded machine relevant data of the last 72 hours of operation can be saved
on an external memory device (USB-stick or SD-CARD).
Plug an USB-stick or a SD-card device in the USB-connection (1) on the back of
the printer.
or
Insert a SD-card in the slot (2) on the controller board in the electronic cabinet.
Press the button <Export> (3).
Now the data are saved on the connected medium and the message <Export is
running…> (4) is displayed during the process.
After finishing the storage the message (5), that the process has been carried out
is faded in. The saving happens with the description „datalog_LJ3-(“serial number
of the printer”).txt“.
Finally confirm the message with the button <OK> (6).
Note: If no storage medium (memory device) is connected, the message (7) is
faded in. Confirm the message with the button <OK> (8). Connect a memory
device and repeat the complete process.
