Group 8 Job editor Page 258
Release R2.0 LEIBINGER JET3
8.5.2.5 Return stop
(Stop backwards)
With the checkbox <lock backward> the function „lock backward movement of the
encoder“ is activated or deactivated.
For activated “lock backward” the strokes which are generated for a possible
backward motion will be included for following forward motion to control the correct
start of the text output.
That means the print will be only continued if the correct printing position has been
reached. Therefore you will get a print without any gaps or overlaps.
8.5.2.6 Speed dependent output
In dependence of a pre-adjusted speed limit, this special output signal switches ON
or OFF. The setting for the output can be found in the main menu under Settings ►
I/O Settings ► Outputs. The speed dependent output can be assigned to any
available output.
Function:
The assigned output switches to high level once the set speed is reached
or exceeded. The assigned output switches back to low level when the
speed falls 10% below the set speed.
Figure 141
Speed dependent output – Setting/diagram
Assigning the speed dependent
output function to an available
output
Basic function diagram
Example:
This function may be used for Corona / Plasma pre-treatment security. A
corona treatment device modifies the surface of materials especially
plastic material as a preparation for the ink jet print. The corona treatment
and the ink jet print happen on the fly. In case the production line stops
or gets too slow there is the danger that the surface of the material can
be destroyed by the corona treatment if the device isn’t stopped. The
stop can be managed by the speed dependent output of the JET 3. In
this example the speed is set to 30 m/min. The speed is
