Leibinger Jet 3 - Basic Operating Processes

Group 6 Operation – Elements and procedures Page 72
Release R2.0 LEIBINGER JET3
6.4.1 Numeric keypad
Figure 21
Numeric keypad design
1 – Display
2 –<Backspace> key
3 –<del> key
4 –<> key
5 –<> key
6 –<Return> key
Numbers are entered with the numeric keypad.
The entered value is shown in the Display (1).
The < Backspace > key (2) deletes the character in front of (to the left of) the
current cursor position.
The <del> key (3) enables the deletion of the characters behind (to the right of) the
current cursor position.
With the <> key (4) you can shift the current cursor position by one digit to the
right.
With the <> key (5) you can shift the current cursor position by one digit to the
left.
With the <Return > key (6) you can take over the input and the Numeric keypad
closes.
2
3
6
1
4
5
