3-13GPS1200
Equipment Setup
Position of cables
in the minipack
a) 1.6 m antenna cable
b) 1.8 m, 8 pin LEMO cable
c) 1.2 m antenna cable to connect radio
housing and radio antenna
c
GPS12_036
a
b
