Leica HDS6000 User Manual

50HDS6000
Preparing to Scan
3.4.2 Menu Control
Main menu After the HDS6000 system start-up you can select from five main menus:
•Info
• Status
• Tilt Sensor
•Scanning
• Scanmanagement
Example display:
The top line indicates the menu currently in use by the HDS6000.
When a appears in the bottom line you can page through the submenu using .
You can change values and parameters using and .
- Info - - - - - - - - - - - Leica
01.09.2008 12:00:00
No 729/050811
IP 172.20.1.125

Leica HDS6000 Specifications

General

Accuracy	6 mm at 50 m
Beam Divergence	0.22 mrad
Field of View (Horizontal)	360°
Field of View (Vertical)	310°
Angular Resolution	0.009°
Interface	Ethernet
Type	Terrestrial Laser Scanner
Measurement Range	0.5 m to 79 m (Object reflectivity dependent)
Point Density	Up to 1 million points per second
Operating Temperature	-10°C to 45°C
Laser Class	Laser Class 1
Laser Type	Infrared
Scan Speed	Up to 500, 000 points/second
