Table of Contents
1 Safety Directions 6
1.1 General 6
1.2 Denition of Use 7
1.3 Limits of Use 7
1.4 Responsibilities 7
1.5 Hazards of Use 8
1.6 Laser Classication 11
1.6.1 General 11
1.6.2 Distancer, Measurements with Reectors 12
1.6.3 Distancer, Measurements without Reectors 12
1.6.4 Red Laser Pointer 14
1.6.5 Laser Plummet 16
1.7 Electromagnetic Compatibility (EMC) 17
1.8 FCC Statement, Applicable in U.S. 19
1.9 ISED Statements (EN/FR), Applicable in Canada 21
2 Description of the System 22
2.1 System Components 22
2.2 Container Contents 23
2.3 Instrument Components 24
3 User Interface 26
3.1 Keyboard 26
3.2 Operating Principles 26
4 Operation 30
4.1 Instrument Setup 30
4.2 Batteries 33
4.2.1 Operating Principles 33
4.2.2 Battery for the iCB Instrument 33
4.3 Data Storage 34
4.4 Distance Measurements - Guidelines for Correct Results 34
5 Check & Adjust 36
5.1 Overview 36
5.2 Preparation 37
5.3 Combined Adjustment (l, t, i and c) 38
5.4 Adjusting the Circular Level of the Instrument and Tribrach 40
5.5 Adjusting the Circular Level of the Prism Pole 41
5.6 Inspecting the Laser Plummet of the Instrument 41
5.7 Servicing the Tripod 42
6 Care and Transport 43
6.1 Transport 43
6.2 Storage 43
6.3 Cleaning and Drying 44
7 Technical Data 45
7.1 Angle Measurement 45
7.2 Distance Measurement with Reectors 45
7.3 Distance Measurement without Reectors
(Non-Prism mode)
46
7.4 LOC8 Theft Deterrence and Location Device (optional) 47
7.5 Conformity to National Regulations 47
7.5.1 iCB50/iCB70 47
7.5.2 LOC8 Theft Deterrence and Location Device (optional) 48
7.5.3 Dangerous Goods Regulations 49
