MS50/TS50/TM50, Table of Contents
5
5Check & Adjust
61
5.1 Overview 61
5.2 Preparation 62
5.3 Combined Adjustment (l, t, i, c, ATR and tele camera) 63
5.4 Tilting Axis Adjustment (a) 65
5.5 Adjusting the Circular Level of the Instrument and Tribrach 66
5.6 Adjusting the Circular Level of the Prism Pole 67
5.7 Inspecting the Laser Plummet of the Instrument 67
5.8 Servicing the Tripod 68
6 Care and Transport
69
6.1 Transport 69
6.2 Storage 69
6.3 Cleaning and Drying 70
6.4 Maintenance 70
7Technical Data
71
7.1 Angle Measurement 71
7.2 Distance Measurement with Reflectors 71
7.3 Distance Measurement without Reflectors 73
7.4 Distance Measurement - Long Range (LO mode) 74
7.5 Automatic Target Aiming ATR 75
7.6 Scanning 77
7.7 PowerSearch PS 78
7.8 Overview Camera 78
7.9 Telescope Camera 78
7.10 SmartStation 79
7.10.1 SmartStation Accuracy 79
7.10.2 SmartStation Dimensions 80
7.10.3 SmartAntenna Technical Data 82
7.11 Conformity to National Regulations 84
7.11.1 MS50/TS50/TM50 84
7.11.2 RadioHandle 85
7.11.3 GS08plus 86
7.11.4 GS12 87
7.11.5 GS14 88
7.11.6 GS15 89
7.11.7 Dangerous Goods Regulations 90
7.12 General Technical Data of the Instrument 91
7.13 Scale Correction 94
7.14 Reduction Formulas 97
8 Software Licence Agreement
99
