MS50/TS50/TM50, Table of Contents
4
Table of Contents
In this manual Chapter Page
1Safety Directions
6
1.1 General Introduction 6
1.2 Definition of Use 7
1.3 Limits of Use 7
1.4 Responsibilities 7
1.5 Hazards of Use 8
1.6 Laser Classification 10
1.6.1 General 10
1.6.2 Distancer, Measurements with Reflectors 10
1.6.3 Distancer, Measurements without Reflectors 11
1.6.4 Red Laser Pointer 13
1.6.5 Autofocus Capability of Telescope Camera 15
1.6.6 Automatic Target Aiming ATR 16
1.6.7 PowerSearch PS 17
1.6.8 Electronic Guide Light EGL 18
1.6.9 Laser Plummet 19
1.7 Electromagnetic Compatibility EMC 20
1.8 FCC Statement, Applicable in U.S. 21
2 Description of the System
25
2.1 System Components 25
2.2 System Concept 28
2.2.1 Software Concept 28
2.2.2 Power Concept 29
2.2.3 Data Storage Concept 29
2.3 Container Contents 30
2.4 Instrument Components 34
3User Interface
36
3.1 Keyboard 36
3.2 Operating Principles 37
3.3 Autofocus Capability of Telescope Camera 38
4Operation
39
4.1 Setting Up the TPS Instrument 39
4.2 Setting Up SmartStation 40
4.3 Setting Up SmartPole 41
4.4 Setting up for Remote Control (with the RadioHandle) 42
4.5 Setting up for Remote Control (with the TCPS29/30) 43
4.6 Fixing the Field Controller to a Holder and Pole 44
4.7 Connecting to a Personal Computer 45
4.8 Power Functions 48
4.9 Batteries 49
4.9.1 Operating Principles 49
4.9.2 Battery for the TS Instrument 49
4.9.3 Battery for SmartAntenna 50
4.10 Working with the Memory Device 52
4.11 LED Indicators 55
4.12 Guidelines for Correct Results 59
